Angle Butterfly Valve with Union Female/Female thread

Item Number : VG14.21061

The Angle Butterfly Ball Valve with Union female-female thread is a high-quality valve manufactured by V&G. This valve is suitable for use in piping water systems that comply with EN13828 standards.

Size and Shape:

This valve is available in sizes ranging from 1/2″ to 2″, making it suitable for use in a variety of piping applications. The valve body is nickel-plated, ensuring durability and resistance to corrosion.

Threads:

The Angle Butterfly Ball Valve features Union female-female threads that comply with ISO 228 standards. These threads are equivalent to DIN EN ISO 228 and BS EN ISO 228 standards, ensuring compatibility with a wide range of piping systems.

Temperature and Pressure Range:

This valve is designed to operate in a wide range of temperatures, from -20°C to 120°C, making it suitable for use in both hot and cold water systems. It has a maximum working pressure of PN25, allowing it to handle high-pressure applications with ease.

+86 576 8742 8589

Quick Dispatch & Fast Delivery

Overview:

Introducing the Angle Butterfly Ball Valve with Union FxM V&G Optima, the perfect addition to any industrial piping system. This top-of-the-line valve combines the best features of a butterfly valve and a ball valve. Ensuring reliable and efficient flow control for your operation.

Crafted from high-quality materials, this valve is built to withstand tough industrial conditions and resist corrosion. The union FxM connection allows for easy installation and maintenance. While the V&G Optima design provides a tight seal, reducing the risk of leaks and ensuring smooth operation.

The angled design of the valve allows for optimal flow control, making it ideal for use in a variety of applications. Including chemical processing, oil and gas, water treatment, and more. Whether you’re looking to upgrade your existing piping system or outfit a new facility, the Angle Butterfly Ball Valve with Union FxM V&G Optima is a reliable choice that you can count on for years to come.



Specifications

MaterialLead,BrassValve TypeBall Valve
BrandMidline ValveWorking mediumWater
Item Dimensions LxWxH2.5 x 0.75 x 0.75 inchesNominal pressure:MOP5
Exterior FinishBrassWorking Temperature:-20 c
Inlet Connection TypeFull portMaterial:Brass
Specification MetCSAThread:Female Thread,apply to GB/T12230 standard
Specification:DN15/20/25/32/40/50/65/80HandleButterfly
